FKM Rubber Precompound 20-60 Mooney Viscosity for Automotive Seals

Cuota De Producción:	20
Precio:	10

Información detallada

Descripción del Producto

Información detallada

Viscosidad de Mooney:

Entre 20 y 60

Compresión:

Espesor:

2mm-8m m

Especificación:

445*305*145m m

F Contenido:

El 66%

Peso específico:

1.81

Forma física:

LOSA

Solubilidad:

Cetonas y ésteres

Mooney Viscosity ML:

Resistencia a la tracción:

15.9 MPa

Alargamiento en el descanso:

210 por ciento

Dureza:

La costa A 75

Compression Set %:

Resistencia a baja temperatura:

-17ºC

Capacidad de producción:

14000 mt/año

Resaltar:

FKM rubber precompound for automotive seals

FKM rubber 20-60 Mooney viscosity

FKM rubber precompound with warranty

Descripción del Producto

Fluoroelastomer FKM for Molding Rubber Parts Copolymer and Terpolymer Available

Company Profile

Founded in 2002, headquartered in Chengdu National Industrial Park - Meishan Jinxiang Industrial Park.

The largest FKM manufacturer in China, with actual output of 5500mt in 2022
2 CNAS approved labs
1 10,000 clarification workshop for smart-wearable devices
1 100,000 clarification workshop for FKM precompounds and compounds
13 producing lines for FKM precompounds and compounds

Product Description

FD-601E is a wide molecular weight distribution fluoroelastomer precompound which includes copolymer of hexa-fluoropropylene and vinylidene-fluoride, curatives.

It is designed for compression molding products such as O-ring, V-ring and gasket.

Basic Characteristics

F Content	66%
Specific Gravity	1.81
Physical form	Slab
Color	Off-white
Solubility	Ketones and Esters
Mooney Viscosity ML 1+10@ 121ºC	61

Features

Excellent performance characteristics:

Excellent low temperature resistance
Excellent chemical resistance
Good mold flow
Low compression set

Recommended Processing Procedures

FD-601E can be compounded with internal mixers or two-roll mills with standard fillers and other ingredients that are used in typical fluoroelastomer formulations. All the dry ingredients should be blended before adding to the rubbery solid. During compounding, full cooling should be accompanied. After mixing, the compound should be cooled as quickly as possible.

Packing Information

FD-601E is packed with PE film in carton. The weight is 20kg net per carton.

Safety and Handling

Store in well ventilated place
Smoking is forbidden strictly in working areas
Avoid eye contact
Wash thoroughly any contacted skin and clothing after handling

For further safety and handling guidance, consult the product's Material Safety Data Sheet or contact Dowhon's representatives.

Typical Properties

Compound	phr
FD-601E	100
N990	30
MgO-150	3
Ca(OH)2	6
Carnauba Wax	1

Rheological Properties

GOTECH Moving Die Rheometer (GT-M3000A) 100 cpm 0.5 Arc 177ºC@ 6min

	Value	Test Method
ML, lb.in	2.21	ASTM D6601
MH, lb.in	21.36	ASTM D6601
Ts2, min	1:08	ASTM D6601
T10, min	1:07	ASTM D6601
T90, min	2:16	ASTM D6601

Physical Properties

Press Cure 180ºC@5min, Post Cure 230ºC@24hour

	Value	Test Method
Tensile Strength, Mpa	15.9	ASTM D412
Elongation at Break, %	210	ASTM D412
Hardness, Shore A	75	ASTM D412

Compression Set %

200ºC@70h	18	ASTM D395, method B

Low Temperature Resistance

Tr10, ºC	-17	ASTM 1329

Packaging & Shipping

20kgs/25kgs per carton by courier (FedEx, DHL etc); 500kgs/625kgs/700kgs per pallet for shipping.

Certifications

ISO9001, ISO14001, ISO16949

Currently holds 65 patents, with 15 invention patents under application. Participated in the formulation of 4 National Standards.

FAQ

What's your MOQ?

By air MOQ is 20-25KG, by sea MOQ is 100KG.

What's your delivery time?

For stock goods, we can arrange delivery within 3 working days, otherwise delivery time is around 7-14 working days.

What's your package?

Usually goods are packaged with PE film in carton. The weight is 20-25kg net per carton. 500kgs/625kgs/700kgs in a pallet.

How can we select the exactly grade which suit for our usage?

Please contact our sales, we'll recommend suitable grade according to your typical physical properties and other related information.
